Cnlinko male and female connector 19-pin circular connector/waterproof connector

Cnlinko M24 Gold Pin Female Terminal 19 Pin Circular ConnectorSupports 24mm mounting hole size.The spring snap-on design is tightly locked and secure.A variety of styles (fiber, USB, RJ45, power supply) to adapt to different industrial needs.Stable power and signal transmission, power multi-core dressing and reverse mounting des

Featured Products

Cnlinko M24 Gold Pin Female Terminal 19 Pin Circular Connector

Supports 24mm mounting hole size.

The spring snap-on design is tightly locked and secure.
A variety of styles (fiber, USB, RJ45, power supply) to adapt to different industrial needs.
Stable power and signal transmission, power multi-core dressing and reverse mounting design (optional slotting).
The power line's unique wire spring technology design is more suitable for stable current transmission and low temperature rise.
The power supply copper pin crimping and soldering optional connection method is fully compatible with outdoor installation work.
The product is IP65/IP67 rated in the connected state.

Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors

Specifications
Connecting modePlug/unplug
Protection levelIP67
Cable specification0.34mm2 ~ 0.75mm2 /22-20AWG
Diameter rangeΦ5.0mm ~Φ6.5mm
Contact diameter×Qty1.0*19
Current rating(A)5A
Operating voltage(AC.V.rms)125V
Withstand voltage(AC.V)1min1000V
Contact resistance<5mΩ
Insulation resistance>500MΩ
Durability≥500 mating&unmating cycles
Temperature rating-40°C~80°C
Prevent the combustion levelUL94-V0
Material
Shell&insulated partsHigh performance engineering plastics
Hardware metalZinc alloy(pearl hard chromium)
Contact pinCopper alloy(gold-plated)
SpringStainless steel
SealingSilica gel
Main characteristics
- Sealed against dust and fluid (IP68)
- Vibration resistance,impact resistance,stretching resistance
- With one hand, can quickly insert or pull out
Application industries
- Stage equipment- The smart grid
- Medical equipment- Server
- Solar energy equipment- Ship equipment
- Electric power equipment- Vehicle equipment
- Communications equipment

Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors
Cnlinko Male Female Connector 19 Pin Circular Connector/Waterproof Connectors

Packaging & Shipping
1. 5pcs to a box, 40 boxes to a carton,or use customized packing with MOQ1000 pcs/model boxes.
2. Lead time: 7-10 working days after received deposit
3. DHL/UPS/Fedex/EMS/TNT(door to door) or use customer partner

Our Service
1. Supply OEM and ODM service
2. With professional quality control system and R&D department
3. To make customized needs with national level laboratory
4. Free samples are available
5. Supply the best service to you with the contact details below:

FAQ:
Q1: What are connectors?
A1: Connectors are connected to the electrical and mechanical components of electrical circuits.
(all in all: cable to cable; cable to machines)

Q2: What classes do connectors have?
ShapeFrequencyFunction
circularhigh-frequencyfor printed board; cabinets;
rectangularlow frequencysocket connectors; for audio equipment, power, signal, etc.

Q3: Why to choose CNLINKO? Any advantages?
A3: The answer is Yes. There are 5 major advantages (reasons).

1) Mutual Benefits: Our connectors are with high quality and competitive in price.
2) Customize: We can make the product as per your special request, Shape and Quality can meet your request.
3) OEM: Design your packing box(≥1000PCS per model).
4) Mix Order: We accept mix order, different model and small quantity order.
5) high quality: Our products have passed UL,CUL,CCC,CE and ROHS certification.

Using PBT material that import from abroad, carrying stable,compression, anti-explosion and anti-deformation quality; Using Zinc alloy material against high frequency noise and electromagnetic interference Use gold-plated contact with high performance of corrosion resistance and electrical conductivity effectively deal with temperature rise.

Q4: Can I order one piece for sample testing usage?
A4: Yes, we recommend you to check the sample before order. Please order the sample from us directly.

Q5: May I have your catalogue and price list for trial order in MOQ quantity?
A5: All our products were shown on alibaba, please have a detailed looking and choose the interested models from our site, sending us inquiry directly, we'll quote you accordingly right away.

Q6: Is there cheap shipping cost to import to our country?
A6: For small order, express will be best. As for bulk order,sea ship way is best but takes much time.
For urgent orders, we suggest via air to airport plus our ship partner send to your door.

Q7:Can we get support if we have our own market position?
A7: Pls inform us your detailed mind on your market demand, we will discuss and propose helpful suggestion for you, to find the best solution for you.
